Products
Ground Utility Inverters
HT Series
(Coming Soon) 225/250KW ∣ Three Phase ∣ 12 MPPT
The new HT Series is the best solution for utilization on large commercial and utility-scale projects. This inverter boasts 12 MPPTs & 1500V DC voltage and is compatible with bifacial modules. It features power line communication (PLC), string level monitoring and incorporated IV-Curve diagnosis for intelligent detection of voltage and current issues. Configuration can be easily done via Bluetooth, and diagnosis and firmware upgrading can be operated remotely. This outstanding set of features was conceived to ensure the lowest levelized cost of electricity (LCOE).
100-136KW ∣ Three Phase ∣ 12 MPPT
The new HT 1100Vdc Series (100-136 KW) is the ultimate high-power string inverter for the C&I sector. The HT series offers up to 12 MPPTs, and is compatible with Bi-facial modules, with a higher threshold of DC current (Max. 15A per string). It includes PLC communication, internal humidity detection. Configuration can be easily done via Bluetooth and firmware diagnosis & upgrading can be operated remotely. The HT series seamlessly incorporates different sets of technical strengths designed to achieve higher savings in the installation, enhance productivity and diversify available monitoring options, taking safety to the maximum possible level in accordance with the strictest industry standards.
Residential Inverters
SDT Series
4-10KW | Three Phase | 2 MPPT | Tigo Integrated
The GoodWe Smart DT series of inverters is specially designed for three-phase home solar systems, covering a wide power range of 4kW, 5kW, 6kW, 8kW, 10kW. The integrated two MPPTs allow two-array inputs from different roof orientations. The SDT series inverter is small, light and easy to install. Suitable for both outdoor and indoor installations, this inverter offers a quiet operation due to its fan-less, natural convection cooling.
Commercial Rooftop Inverters
Smart DT Series
12-20KW | Three Phase | 2 MPPT
The GoodWe Smart DT series of inverters is specially designed for three-phase rooftop systems, the power range of 12kW, 15kW, 17KW and 20kW are ideal for small commercial usage. The integrated two MPPTs allow two-array inputs from different roof orientations. The SDT series inverter is small, light and easy to install. Suitable for both outdoor and indoor installations, this inverter offers a quiet operation due to its fan-less, natural convection cooling.
LVSMT Series
12-20KW | Three-Phase | 3 MPPT | Low Voltage
GoodWe’s LVSMT series three-phase inverter is designed with low voltage power input, specifically tailored to small commercial PV applications. Developed as an efficient response to South American market needs for low-voltage inverters above 10kW, the GoodWe LVSMT series is applicable to the different grid voltage ranges in the region, which mainly cover 208V, 220V and 240V. With the GoodWe LVSMT series inverter, the system configuration can be simplified by avoiding the installation of an expensive transformer which adversely affects the system’s conversion efficiency.
LVDT/DT Series
12-25KW | Three Phase | 2 MPPT
GoodWe’s DT series inverter is suited for commercial and industrial roofs as well as small and medium-sized photovoltaic power systems. Because of the reliable grid support capabilities, high grade waterproofing and dustproofing alongside extra-wide voltage range module, it can not only be used in commercial roof and commercial power station PV systems, but also is qualified for the design requirements of large-megawatt power stations.
SDT G2 Series
17-25KW ∣ Three Phase ∣ 2 MPPT
The GoodWe 17-25KW SDT G2 series inverter is especially designed for three-phase residential and small commercial projects. With its compact design, the SDT G2 inverter is 45% smaller than the first generation. The inverter is also light and easy to install. The max efficiency of this inverter is as high as 98.4%. With an advanced ventilation system, the inverter is able to dissipate heat efficiently. In addition, it can be customised with an integrated shiny LCD screen.
SMT Series
25-36KW | Three Phase | 3 MPPT
GoodWe’s brand new SMT series of inverter is ideal for medium and large-scale commercial rooftop installations, providing a maximum efficiency of 98.8 percent and up to three MPPT routes for particular environments. With a weight of just 40 kg and a compact, efficient design, the SMT series is easier to handle and install in comparison to similar inverters in the market. Featuring a maximum DC input voltage of 1100V, wider MPPT range, and a start-up voltage of 180 V, the SMT series guarantees earlier power generation and longer working time in order to maximize long-term returns and profitability for the system owner.
LVMT Series
30-50KW | Three Phase | 4 MPPT | Low Voltage
The second generation of GoodWe’s MT series inverter is suitable for medium and large scale commercial rooftops or ground-mounted solar PV systems where maximum versatility and profitability are important. With its compact design and power boost function, GoodWe’s MT G2 series can provide extremely high efficiency of 98.8%, thus offering a faster return on investment.
MT Series
50-80KW | Three Phase | 4 MPPT
GoodWe’s MT series of inverter is ideal for medium to large-sized distribution projects, especially for large-scale commercial roofs and farm plants. The range boasts advanced topology and innovative control technology to achieve a maximum efficiency of 99.0%, aimed at maximising long-term returns and profitability for the system owner.
